It is highly suitable for areas with intensive charging needs. Equipped with an advanced control system and communication modules, it supports functions such as intelligent scheduling, remote monitoring, and fault diagnosis. It also supports connectivity with major mainstream electric car charging station management platforms. Through its connection to the cloud platform, operators can monitor the real-time operating status of the charging station, enabling remote maintenance and upgrades.
| Category | Specifications | Data Parameters |
|---|---|---|
| Appearance structure | Dimensions (L x D x H) | 900 * 900 *1975mm |
| Weight | 480kg | |
| Length of charging cable | 5m | |
| Connectors | CCS1 || CCS2 || CHAdeMO || GBT Three Guns * Four Guns | |
| Electrical indicators | Input Voltage | 400VAC / 480VAC (3P+N+PE) |
| Input frequency | 50/60Hz | |
| Output Voltage | 200 - 1000VDC | |
| Output current | 0 to 800A | |
| Rated power | 60-240kW | |
| Efficiency | ≥94% at nominal output power | |
| Power factor | >0.98 | |
| Communication protocol | OCPP 1.6J | |
| Functional design | Display | 7’’ LCD with touch screen |
| RFID system | ISO/IEC 14443A/B | |
| Access Control | RFID: ISO/IEC 14443A/B || Credit Card Reader (Optional) | |
| Communication | Ethernet – Standard || 3G/4G Modem (Optional) | |
| Power Electronics Cooling | Air Cooled | |
| Work environment | Operating temperature | -30 °C to 55 °C |
| Working || Storage Humidity | ≤ 95% RH || ≤ 99% RH (Non-condensing) | |
| Altitude | < 2000m | |
| Ingress Protection | IP54 || IK10 | |
| Safety design | Safety standard | GB/T, CCS2, CCS1, CHAdeMo, NACS |
| Safety protection | Overvoltage, lightning, overcurrent, leakage, waterproof protection, etc | |
| Emergency Stop | Emergency Stop Button Disables Output Power |
