Product Description
160KW DC charging pile is a device used to quickly charge new energy electric vehicles. DC charging pile has the charging characteristics of strong compatibility and fast charging speed. 160KW DC electric vehicle charger has two kinds of specifications: national standard, European standard, double-gun charger, single-gun charger and two types of chargers. With the rapid development of new energy electric vehicles, DC chargers are also widely used in airports, car parks, bus stops and other scenes. DC charging piles can be used not only to charge personal electric vehicles, but also for charging stations in public places. In the popularization of electric vehicles, DC charging piles also play a crucial role, which can meet the needs of users for fast charging and improve the convenience of using electric vehicles.
Product Features
Fast charging ability
Electric vehicle DC charging pile has fast charging ability, which can provide electric energy to electric vehicles with higher power and greatly shorten the charging time.
High compatibility
Suitable for various models and brands of electric vehicles, enhancing the versatility and convenience of charging facilities.
Safety Protection
Built-in multiple safety protection mechanisms including over-current, over-voltage, and short-circuit protection to ensure a stable charging process.
Intelligent functions
Features such as remote monitoring, payment systems, and user identification allow real-time status tracking and personalized services.
Energy management
Connected to energy management systems for centralized control, improving efficiency and sustainability for operators.
Product Specification
| 160KW-Body DC Charger |
| Equipment type |
BHDC-160KW |
| AC input |
AC Input Voltage Range (v) |
380±15% |
| Frequency range (Hz) |
45~66 |
| Input Power Factor Electricity |
≥0.99 |
| Turbulent Noise Diffusion (THDI) |
≤5% |
| DC Output |
efficiencies |
≥96% |
| Output Voltage Range (V) |
200~750 |
| Output power(KW) |
160 |
| Maximum output current (A) |
320 |
| charging port |
1/2 |
| Charging gun length (m) |
5m |
| Additional information |
Voice (dB) |
<65 |
| Stabilization accuracy |
<±1% |
| Voltage stabilization accuracy |
≤±0.5% |
| Output current error |
≤±1% |
| Output Voltage Error |
≤±0.5% |
| equalization unbalance |
≤±5% |
| human-machine display |
7-inch color touch screen |
| Charging operation |
Swipe or Scan |
| Metering and billing |
DC Energy Meter |
| Operating instructions |
Power, Charging, Fault |
| Communication |
Standard Protocol |
| Heat dissipation control |
air cooling |
| Protection class |
IP54 |
| BMS auxiliary power |
12V/24V |
| Charge Power Control |
Intelligent Distribution |
| Reliability(MTBF) |
50000 |
| Dimension(W*D*H)mm |
700*565*1630 |
| Installation |
Integral floor standing |
| Alignment |
undercurrent |
| working environment |
Altitude(m) |
≤2000 |
| Operating Temperature(°C) |
-20~50 |
| Storage Temperature(°C) |
-20~70 |
| Average Relative Humidity |
5%-95% |
| Options |
4G wireless communication |
charging gun 8m/10m |
Product Application
DC charging piles are widely used in public charging stations, highway service areas, commercial centers and other places, and can provide fast charging services for electric vehicles. With the popularization of electric vehicles and the continuous development of technology, the application range of DC charging piles will gradually expand.
Frequently Asked Questions (FAQ)
1. How fast can a 160KW DC charging pile charge an EV?
The 160KW DC charger is designed for rapid charging, capable of providing a significant amount of energy in a short period. Depending on the vehicle's battery capacity, it can often charge an EV to 80% in approximately 30-45 minutes.
2. Is the 160KW DC charging pile compatible with my vehicle?
Our charging piles offer high compatibility, supporting both National and European standards. It is suitable for most major brands of new energy electric vehicles.
3. Can this charging pile be installed outdoors?
Yes, the device features an IP54 protection rating, making it resistant to dust and water splashes, suitable for outdoor installation in car parks, bus stops, and highway service areas.
4. Does the charger support simultaneous dual-gun charging?
The 160KW DC charger comes in both single-gun and double-gun specifications. The double-gun version features intelligent power distribution to charge two vehicles simultaneously.
5. How is the charging process monitored and paid for?
Users can start charging by swiping a card or scanning a QR code. The 7-inch color touch screen provides real-time status, and the system supports remote monitoring and various payment integrations.
6. What safety features are included to protect the battery?
The system includes comprehensive protections such as over-voltage, over-current, short-circuit, and insulation monitoring, ensuring the safety of both the charging pile and the vehicle's battery.
