| Category | Specifications | Data Parameters |
|---|---|---|
| Appearance Structure | Dimensions (L x D x H) | 660mm x 770mm x 1000mm |
| Weight | 120kg | |
| Length of charging cable | 3.5m | |
| Connectors | CCS1 || CCS2 || CHAdeMO || GBT | |
| Electrical Indicators | Input Voltage | 400VAC / 480VAC (3P+N+PE) |
| Input frequency | 50/60Hz | |
| Output Voltage | 200 - 1000VDC | |
| Output current | CCS1 – 120A || CCS2 – 120A || CHAdeMO – 120A || GBT- 120A | |
| Rated Power | 40kW | |
| Efficiency | ≥94% at nominal output power | |
| Power Factor | >0.98 | |
| Communication Protocol | OCPP 1.6J | |
| Functional Design | Display | No |
| RFID System | ISO/IEC 14443A/B | |
| Access Control | RFID: ISO/IEC 14443A/B || Credit Card Reader (Optional) | |
| Communication | Ethernet – Standard || 3G/4G Modem (Optional) | |
| Power Electronics Cooling | Air Cooled | |
| Work Environment | Operating Temperature | -30°C to 75°C |
| Working || Storage Humidity | ≤ 95% RH || ≤ 99% RH (Non-condensing) | |
| Altitude | < 2000m | |
| Ingress Protection | IP30 | |
| Safety Design | Safety Standard | GB/T, CCS2, CCS1, CHAdeMo, NACS |
| Safety Protection | Overvoltage protection, lightning protection, overcurrent protection, leakage protection, waterproof protection, etc. |
