This product boasts a self-developed, brand-new appearance and supports customized design, maximizing customer satisfaction in terms of visual appeal. It can be adjusted to power levels ranging from 60 kW to 240 kW according to specific needs. This product has obtained CE certification and is suitable for operation and use in urban dedicated charging stations, urban public charging stations, intercity highway charging stations, and other related locations.
Equipped with advanced control systems and communication modules, it supports functions such as intelligent scheduling, remote monitoring, and fault diagnosis.
It can connect with major mainstream ev charging pile management platforms. Through the cloud platform, operators can monitor real-time status and perform remote upgrades.
Through its connection to the cloud platform, operators can monitor the real-time operating status of the level 3 charging piles, perform remote maintenance and upgrades, thereby enhancing the utilization rate and reliability of the charging piles.
| Category | Specifications | Data Parameters |
|---|---|---|
| Appearance Structure | Dimensions (L x D x H) | 750mm x 750mm x 1880mm |
| Weight | About 310kg (including wooden crate) | |
| Length of Charging Cable | 5m | |
| Connectors | CCS1 || CCS2 || CHAdeMO || GBT || NACS | |
| Electrical Indicators | Input Voltage | 400VAC / 480VAC (3P+N+PE) |
| Input Frequency | 50/60Hz | |
| Output Voltage | 200 - 1000VDC (Constant power: 300 - 1000VDC) | |
| Output Current (Air Cooled) | CCS1 - 200A || CCS2 - 200A || CHAdeMO - 150A || GBT - 250A || NACS - 200A | |
| Output Current (Liquid Cooled) | CCS2 - 500A || GBT - 800A || GBT - 600A || GBT - 400A | |
| Rated Power | 60-240kW | |
| Efficiency | ≥ 94% at nominal output power | |
| Power Factor | 0.98 | |
| Communication Protocol | OCPP1.6J | |
| Functional Design | Display | 7" LCD with touch screen |
| RFID System | ISO/IEC 14443A/B | |
| Access Control | RFID: ISO/IEC 14443A/B || Credit Card Reader (Optional) | |
| Communication | Ethernet - Standard || 3G/4G || Wifi | |
| Power Electronics Cooling | Air Cooled || Liquid Cooled | |
| Work Environment | Operating Temperature | -30°C to 55°C |
| Working || Storage Humidity | ≤ 95% RH || ≤ 99% RH (Non-condensing) | |
| Altitude | < 2000m | |
| Ingress Protection | IP54 || IK10 | |
| Safety Design | Safety Standard | GB/T, CCS2, CCS1, CHAdeMo, NACS |
| Safety Protection | Overvoltage protection, lightning protection, overcurrent protection, leakage protection, waterproof protection, etc. | |
| Emergency Stop | Emergency Stop Button Disables Output Power |
