"Energy Refueling Stations" for New Energy Vehicles: 80 kW and 120 kW DC Fast Charging Stations
🔌
Multi-Standard Support
Full compatibility with CCS2, Chademo, and Gbt standards, ensuring seamless charging for diverse EV fleets worldwide.
⚡
High Power Levels
Available in 120kW, 160kW, and 180kW options to drastically reduce charging time from hours to just a few minutes.
🏗️
Robust Design
Floor-standing structure provides high visibility, stability, and durability for public and commercial high-traffic locations.
One of the best things about this charger station is that it supports multiple charging standards, including CCS2, Chademo, and Gbt. This versatility means that a wide range of electric vehicles, no matter what brand or model, can be charged at the station. CCS2 is a popular standard in Europe and many other regions. It offers a seamless and efficient charging experience. Chademo is used a lot in Japan and some other markets. Gbt also contributes to the station's ability to accommodate diverse EV fleets. This compatibility not only provides convenience to EV owners but also promotes interoperability and standardization within the EV ecosystem.
What sets this station apart from many conventional chargers is that it offers 120kW, 160kW, and 180kW charging options. These high power levels mean you can charge in a lot less time. For instance, an electric vehicle with a medium-sized battery pack can get a big charge in just a few minutes, instead of hours. A 120kW charger can add a lot of range in a short time, while the 160kW and 180kW versions can even speed up the charging process even more. This is a big deal for EV drivers who are on long trips or have tight schedules.
Car Charger Parameters
| Model Name |
BHDC-80KW-2 |
BHDC-120KW-2 |
| AC Nominal Input |
| Voltage (V) |
380±15% |
| Frequency (Hz) |
45-66 Hz |
| Input Power Factor |
≥0.99 |
| Current Harmonics (THDI) |
≤5% |
| DC Output |
| Efficiency |
≥96% |
| Voltage Range (V) |
200~750V |
| Power Output |
80KW |
120KW |
| Current Output |
160A |
240A |
| Charging Ports |
2 |
| Cable Length |
5M |
Technical Parameters
| Equipment Information |
Specification |
| Operational Specs |
Noise (dB) |
＜65 |
| Precision of Steady Current |
≤±1% |
| Voltage Regulation Accuracy |
≤±0.5% |
| Output Current Error |
≤±1% |
| Output Voltage Error |
≤±0.5% |
| Screen Display |
7 Inch industrial screen |
| Charging Operation |
Swiping Card |
| Energy Meter |
MID certified |
| Environment & Protection |
Protection Grade |
IP 54 |
| Cooling Method |
Air cooling |
| BMS Auxiliary Power |
12V/24V |
| Installation Method |
Pedestal installation |
Frequently Asked Questions (FAQ)
What charging standards are supported by these DC stations?
The stations support CCS2, Chademo, and Gbt standards, making them compatible with almost all electric vehicles from Europe, Japan, and other global markets.
How fast can these stations charge an electric vehicle?
With power levels of 120kW, 160kW, and 180kW, these chargers can provide a significant range boost in just a few minutes, significantly reducing wait times compared to standard AC chargers.
Are these charging piles suitable for outdoor installation?
Yes, they feature an IP54 protection grade and a sturdy floor-standing design, ensuring reliable operation in various environmental conditions like public parking lots and highway rest areas.
Can two vehicles charge at the same time?
Yes, the 80kW and 120kW models come equipped with two charging ports, allowing for multiple vehicle sessions.
What is the efficiency of the DC output?
The charging stations are highly efficient, maintaining a DC output efficiency of ≥96%, which minimizes energy loss during the charging process.
How is the charging process monitored and controlled?
The stations feature a 7-inch industrial screen for user interaction, support card swiping for operation, and include LED indicators to show the current status (green/yellow/red).
